STUDENT MICROSCOPE

Product Description

Being a client centric organization, we are engaged in manufacturing, exporting and supplying Student Microscope to the clients. Having its use for the laboratory examination of microorganisms, this microscope is commonly used in the laboratories of schools, colleges and institutes. The provided microscope is manufactured by the team of our skilled professionals using the best grade components and the progressive methodology at our advanced manufacturing setup. Besides, we provide this Student Microscope at highly reasonable rates to the clients.

Features:

STUDENT MICROSCOPE

We offer Student Microscope with following technical specification:

Stand                    Stable & Robust, traditional Horse Shoe base.

Body                  Inclined through 90 deg, standard tube length of 160 mm

Focusing         Separate coarse and fine focusing knobs with graduation on one side.

Nose piece        Triple revolving Nose piece is provided with positive click stop for proper centering.

Stage                   Fixed square stage 125 x 125 mm with stage clips to hold the slide.

Illumination        Illumination through a 50 mm diameter plano concave mirror mounted on   gimbal mount.

Objectives          Two Achromatic Objectives of 10x & 40x (SL)

Eyepieces            Two  Eyepiece of 6x, 10x, or 15x

Condenser          Sub stage Abbe condenser with N.A. 1.25 moves up and down by rack & pinion. Iris diaphragm and filter  holder are mounted with the condenser.
