Laminar Air flow cabinet vertical

Product Description

Designed so as to meet the requirements of US Federal standard 209 B (BS 5295) providing particle free air to meet class conditions. The cabinets are fabricated out of thick board duly sunmica clad. Interior surface are epoxy painted for its longer life. The work table is made of thick board which is sunmica clad at top. Side panel are made out of thick transparent plexi glass duly framed. The unit is fitted with pre filter. Air is drawn through pre filter and is made to pass through highly effective HEPA (high efficiency particular air) filters having efficiency ratio as high as 99.99% with cold DOP and 99.97% with hot DOP thus retaining all air home particles of size 0.3 micron and larger. Using a dynamic machine, the blower and motor assembly is statically and balanced ESE MARKED motor of 1/5 H.P. capacity operators with minimum noise level. The working area is illuminated by fluorescent lighting fitted to the unit. Height of the working table provides comfortable ‘SIT DOWN’ working position for the operation. To work on 220/230 volts A.C. supply. Supplied complete with sunmica table top. HEPA filters, pre filter and fluorescent illumination.

MODEL                                                 LH-22        LH-32            LH-42            LH-62                                LH-82

Working size                                     2`x2`x2`   3`x2`x2`       4`x2`x2`       6`x2`x2`           8`x2`x2`

Size of HEPA filter                           2`x2`x6`   3`x2`x6`       4`x2`x6`       3`x2`x6`           4`x2`x6`

No. of HEPA filter                            1                  1                      2                      2                          2

Illumination                                       1 x 20w     1 x 20w         2 x 40w         2 x 40w             4 x 40w
